Description
Additional Details
Core Size: 27-9/16 x 16-1/4 x 11/16 Tank Size: Inlet 16-5/16 x 1-7/16, Outlet 16-5/16 x 1-7/16 Hose Fittings: Top 1-3/8 Right, Bottom 1-3/8 Left No. of Rows: 1 Oil Cooler: No ENGINEERING
CAD/CAM designed using Unigraphics™ Software
Milatary Grade (special clad) aluminum used for tubes, fins, fitments, and side brackets (JIS 3003 spec minumum)
"B-Tube" Technology - Most efficient tube in the world
High Efficiency Louvered Fin
OE radial and deep drawn aluminum endtanks
Wind tunnel tested for optimal radiator core cooling performance
Stronger joint design for mountings, fan shrouds & condensers
OE Specific Mounting
"Drop-in" fitment requiring no modifications
CNC Machined brackets and fittings
Racing Style all-aluminum drain plug
MANUFACTURING
Brazed in CAB Furnace
ISO 9001/9002 certification
Privately owned factories with full "In house" toolrooms
"Master Class" TIG welding
TESTING
Individually leak tested
Vibration cycle tested
Thermal cycle tested
Burst pressure cycle tested 10,000 times for strength
Salt spray tested for corrosion protection
10 foot box "drop test" to ensure packaging protection
FINISH
30 minute, hand polished "Sho-Stopper™ mirror finish"
PACKAGING
Application specific foam packaging
Industry leading, shock resistant 5-ply box
REPUTATION
Over 45+ years in business
Over 500,000 radiators and condensers sold every year
Over 35 million radiators sold worldwide
Over 10 world's first exclusive applications
Installation Notes
Installation Difficulty:
Skill Level 3 -
Advanced
Installation Time: 2-3 hours
Parts Included
Warranty
2 Year Limited Warranty
Specifications
- Engine Size: 2.0L I-4, 2.4L I-4
- Engine Fuel: Gasoline
- Shipping Weight: 9lb
- Shipping Dimensions: 33in x 21in x 6in (L x W x H)
Fitment
- 2016 Jeep Compass (MK)
- 2015 Jeep Compass (MK)
- 2014 Jeep Compass (MK)
- 2013 Jeep Compass (MK)
- 2012 Jeep Compass (MK)
- 2011 Jeep Compass (MK)
- 2010 Jeep Compass (MK)
- 2009 Jeep Compass (MK)
- 2008 Jeep Compass (MK)
- 2007 Jeep Compass (MK)
- 2011 Jeep Patriot (MK)
- 2010 Jeep Patriot (MK)
- 2009 Jeep Patriot (MK)
- 2008 Jeep Patriot (MK)
- 2007 Jeep Patriot (MK)
Additional Information
Engine Size: |
2.0L I-4, 2.4L I-4 |
Engine Fuel: |
Gasoline |
Compatible Vehicle: |
Compass MK 2007-2016 |
Compatible Vehicle: |
Patriot MK 2007-2011 |
