Description
FOX 2.5 Performance Series HTO Coil-Over is a bolt-on shock loaded with position-sensitive technology, vehicle-specific valving, and larger pistons to improve on and off-road performance. A type II anodized aluminum body efficiently dissipates heat and prevents corrosion. The 2.5-inch shock body features an internal floating piston (IFP) to separate the shock oil from the high-pressure nitrogen, optimizing damping.
Hydraulic Top Out (HTO) technology offers usable position-sensitive rebound damping control on and off the pavement. HTO reduces harsh top-outs and increases comfort by forcing shock oil through a secondary shim stack to slow down shock shaft speed; HTO is particularly beneficial after installing heavier, aggressive tires and applications lifted higher than OEM specification.
Bolt-on 2.5 Performance Series HTO Coil-overs to increase damping capacity and ride in comfort with position-sensitive rebound control.
Features and Benefits
Specifications
Frequently Asked Questions (FAQs)
Q: How does the 2.5-inch shock body improve performance?
A: The larger 2.5-inch aluminum body increases oil capacity and heat dissipation, allowing better shock control and durability on lifted Jeep JL models.
Q: How does this shock improve off-road handling?A: It provides enhanced damping to control wheel movement, improve traction, and reduce bottoming out on rough terrain.
Q: Are these shocks direct bolt-on replacements?A: Yes, they use factory mounting points and hardware for straightforward installation.
Product Specifications
- Adjustable: No
- Collapsed Length: 19.04in
- Color: Silver
- Damper Type: Monotube
- Extended Length: 29.72in
- Lift: 2-3in
- Location: Rear
- Material: 6061-T6 Aluminum
- Quantity: 1
- Travel Length: 10.69in
- Install Method: Bolt On
