19.25 in. Fabricated Steel Antirock Sway Bar Arms are available separately for custom builders or as replacement parts for existing kits.
Arms are laser cut & welded steel, 19.25 in. long, 3/8 in. thick and feature a 1.70 in. offset bend.
The 5 adjustable sway bar end link mounting holes at the end of the arm also allow for the use of our Double Sheer End Link Bracket Kit.
Kit Fits:
Universal Applications
Kit Includes:
19.25 in. Antirock Sway Bar Arms (pair) Arm Stickers (pair)
Specs. and Dimensions:
Overall length = 19.25 in. Thickness = 3/8 in. Material = laser cut steel Offset Bend = 1.70 in. Spline count = 25 Center of splined hole to center of 1/2 in. hole #1 (nearest) = 13.95 in. Center of splined hole to center of 1/2 in. hole #2 = 14.95 in. Center of splined hole to center of 1/2 in. hole #3 (middle) = 15.95 in. Center of splined hole to center of 1/2 in. hole #4 = 16.95 in. Center of splined hole to center of 1/2 in. hole #5 (farthest) = 17.95 in. Weight = 9lbs. (for the pair)
Notes:
Arms may be used in conjunction with our Double Sheer End Link Bracket Kit. This bracket kit adds 1 1/2 in. in arm length and the ability to offset the end link up to 1 1/4 in. AntiRock Arm Hardware Kit (sold separately).
Product Specifications
- Arm Material: Steel
- Install Method: Bolt On
- Size: 19.25in
- Type: Sway Bar Arms
- Color: Black
