Description
The complete Tera60 HD Front Axle Assembly w/ Locking Hub provides a choice of pre-installed Super 60 ring & pinion gears, ARB air locker, SlimLock Hub Kit, Spicer HD Ball Joints as well as inner and outer axle shafts, knuckle assembly, brakes, and sensors.
TeraFlex HD Front Axle Housings are perfect for replacing bent, broken, or damaged axles in JL Wrangler/Unlimited and JT Gladiator vehicles including Rubicon models. Can also be used as a direct bolt-on upgrade for Jeep owners looking to beef up the stock axles' weak areas.
Tera60 HD Front Axle Housings are the ultimate upgrade for JL and JT models requiring maximum suspension up travel and compression. Compatible with all Super 60 gear ratios for extreme duty applications requiring additional ring and pinion strength.
Our heavy-duty axle housings feature smooth profile surfaces, axle tubes, all necessary mount brackets, control arm bushings, forged inner knuckles, and more!
Includes:
- ARB Air Locker
- Spicer Super 60 ring & pinion
- Spicer bearings and install kits
- 35-spline inner axle shafts
- 35-spline outer stub shafts
- Spicer HD Ball Joints
- 1350 series pinion yoke
- Dana 60: SlimLock Hub Kit (# 3449350)
- Delta Brake Kit - Front (# 4403481)
- HD Chromoly Tie Rod Kit (# 1863910)
- HD Differential Cover Kit
Fitment:
- JL Wrangler (2-door)
- JL Wrangler Unlimited (4-door)
- JT Gladiator (pickup)
- 0-6 Inch Lift
Specs:
- WMS-WMS: 70 Inch
- Axle Tube: 3.25 Inch x 0.375 Inch
- Wheel Bolt Pattern: 8x6.5 Inch
- Gear Ratio: 4.88
Additional Information
Axle Model: |
Tera60 |
Axle Position: |
Front |
Features: |
4.88 Ratio |
Shipping Weight: |
500lb |
Shipping Dimensions: |
70in x 30in x 24in (L x W x H) |
Compatible Vehicle: |
Gladiator JT (2019-2026) |
Compatible Vehicle: |
Wrangler JL (2018-2026) |
